Deploying Apache DolphinScheduler 3.1.9 Cluster with MySQL Instead of PostgreSQL? A Practical Docker Compose Guide
Download the MySQL JDBC Driver
wget https://downloads.mysql.com/archives/get/p/3/file/mysql-connector-j-8.0.33.zip unzip -q mysql-connector-j-8.0.33.zip cp mysql-connector-j-8.0.33/mysql-connector-j-8.0.33.jar . Prepare Custom Images
Dockerfile for Master, Worker, API, and Alert Server
# Based on the official DolphinScheduler image ARG SERVICE=api FROM apache/dolphinscheduler-${SERVICE}:3.1.9 # Copy the MySQL JDBC driver into the DolphinScheduler library directory # DolphinScheduler loads JDBC drivers from the lib directory COPY mysql-connector-j-8.0.33.jar /opt/dolphinscheduler/libs/ Dockerfile for Tools
# Based on the official DolphinScheduler image ARG SERVICE=tools FROM apache/dolphinscheduler-${SERVICE}:3.1.9 # Copy the MySQL JDBC driver into the DolphinScheduler tools library directory # DolphinScheduler loads JDBC drivers from the lib directory COPY mysql-connector-j-8.0.33.jar /opt/dolphinscheduler/tools/libs/ Build Custom Images
docker build --build-arg SERVICE=master -t apache/dolphinscheduler-master:3.1.9-mysql . docker build --build-arg SERVICE=worker -t apache/dolphinscheduler-worker:3.1.9-mysql . docker build --build-arg SERVICE=tools -t apache/dolphinscheduler-tools:3.1.9-mysql . docker build --build-arg SERVICE=api -t apache/dolphinscheduler-api:3.1.9-mysql . docker build --build-arg SERVICE=alert-server -t apache/dolphinscheduler-alert-server:3.1.9-mysql . Update docker-compose.yaml
Disable the PostgreSQL service and add a MySQL service as the metadata database.
# Comment out the PostgreSQL service # dolphinscheduler-postgresql: # image: bitnami/postgresql:15.2.0 # ... # MySQL Metadata Database Service dolphinscheduler-mysql: image: mysql:8.0 container_name: dolphinscheduler-mysql profiles: - all - schema environment: MYSQL_ROOT_PASSWORD: ${MYSQL_ROOT_PASSWORD:-root} MYSQL_DATABASE: ${MYSQL_DATABASE:-dolphinscheduler} volumes: - dolphinscheduler-mysql:/var/lib/mysql ports: - "3306:3306" # Expose MySQL to allow workers on other servers to connect healthcheck: test: [ "CMD", "mysqladmin", "ping", "-h", "localhost", "-u", "${MYSQL_USERNAME:-root}", "-p${MYSQL_PASSWORD:-root}" ] interval: 5s timeout: 60s retries: 120 networks: - dolphinscheduler The remaining services (ZooKeeper, Schema Initializer, API, Alert Server, Master, Worker, Network, and Volume configurations) remain the same as the official Docker Compose deployment, with the following key modifications:
Schema Initializer Dependency
depends_on: dolphinscheduler-mysql: condition: service_healthy Master JVM Configuration
environment: JAVA_OPTS: > -server -Duser.timezone=${SPRING_JACKSON_TIME_ZONE} -Xms8g -Xmx8g -Xmn4g -XX:+PrintGCDetails -Xloggc:gc.log -XX:+HeapDumpOnOutOfMemoryError -XX:HeapDumpPath=dump.hprof Worker JVM Configuration
environment: JAVA_OPTS: > -server -Duser.timezone=${SPRING_JACKSON_TIME_ZONE} -Xms8g -Xmx8g -Xmn4g -XX:+PrintGCDetails -Xloggc:gc.log -XX:+HeapDumpOnOutOfMemoryError -XX:HeapDumpPath=dump.hprof Volume Configuration
volumes: # Comment out PostgreSQL volume # dolphinscheduler-postgresql: dolphinscheduler-mysql: dolphinscheduler-zookeeper: dolphinscheduler-worker-data: dolphinscheduler-logs: dolphinscheduler-shared-local: Update the .env File
# Docker Hub Repository and Image Tag HUB=apache TAG=3.1.9 # MySQL Configuration MYSQL_ROOT_PASSWORD=root MYSQL_DATABASE=dolphinscheduler MYSQL_USERNAME=root MYSQL_PASSWORD=root # DolphinScheduler Database Configuration TZ=Asia/Shanghai # Use MySQL as the metadata database DATABASE=mysql SPRING_JACKSON_TIME_ZONE=GMT+8 SPRING_DATASOURCE_URL=jdbc:mysql://dolphinscheduler-mysql:3306/${MYSQL_DATABASE}?useUnicode=true&characterEncoding=UTF-8&useSSL=false&serverTimezone=Asia/Shanghai&allowPublicKeyRetrieval=true SPRING_DATASOURCE_USERNAME=${MYSQL_USERNAME} SPRING_DATASOURCE_PASSWORD=${MYSQL_PASSWORD} REGISTRY_ZOOKEEPER_CONNECT_STRING=dolphinscheduler-zookeeper:2181 MASTER_FETCH_COMMAND_NUM=10 Initialize the Database
docker compose --profile schema up -d Start the Entire Cluster
docker compose --profile all up -d Start the Worker Service
docker compose up -d dolphinscheduler-worker Start the Master Service
docker compose up -d dolphinscheduler-master Start the Alert Service
docker compose up -d dolphinscheduler-alert Start the API Service
docker compose up -d dolphinscheduler-api Restart All Services
docker compose --profile all restart Conclusion
Although Apache DolphinScheduler officially ships with a PostgreSQL-based Docker Compose deployment, many enterprises continue to standardize on MySQL for operational consistency and ecosystem compatibility.
By adding the MySQL JDBC driver, rebuilding the DolphinScheduler images, and adjusting the Docker Compose and environment configurations, you can quickly deploy a fully functional Apache DolphinScheduler 3.1.9 cluster powered by MySQL metadata storage.
This approach enables teams already invested in the MySQL ecosystem to integrate DolphinScheduler into their infrastructure with minimal friction while preserving the benefits of containerized deployment and cluster-based scheduling.
If your organization relies on MySQL as a strategic database platform, this solution provides a practical and production-friendly path to running Apache DolphinScheduler at scale.
